Anti-terrorism bollard tested and certified (crash-tested) by an independent company according to standards IWA14-1:2013 V/7200[N3C]/80/90 (equivalent to american standard “K12”). Each bollard has an independent pump so that in the event of a control unit failure, the other bollards in the environment remain functional.
| Operator | hydraulic bollard |
| Voltage | 230v |
| Shaft height | 1200 mm |
| Thickness | 25mm |
| Shaft diameter | 330 mm |
| Rising time | max 5.3 sec |
| Shaft treatment* | RAL 7015 painted steel and reflective film h:100 mm |
| Lowering time | 4 sec |
| Control unit | PERSEO CBE 230.P SD |
| Break-in resistance | 2100000J |
| Frequency of use | 2000 op/day |
| Anti-terrorism reference standard | IWA14-1:2013 V/7200[N3C]/80/90 |
| Type of limit switch | reed magnetic sensor |
| Manual operation | reversible with mechanical key with no power |
| Ambient conditions | 40°C +60°C |
